This Multi Track Sachet Packing Machine is used for dispensing powder or granule products and sealing them in the form of a 3/ 4 side-sealed sachet.Vertical Powder Multi-Channel Conveyor Packaging Machine includes the sachet forming, product dosing, filling, and sachet sealing processes,with either single or string sachet cutting—servo-driven piston pump with shut-off apertures for maximum precision and zero leakage.
Model:Multi lines packaging machine
Lanes:2.4.6.8.10.12 (customized)
Package shape:4 side sealer bag
Filling:granule,powder
Stick Filling Weight:5 gr. – 20 gr.
Packaging speed:40 to 50 bag/min per line
Bag length:20-120mm
Bag width:10 to 60mm / 620mm
Diameter of packaging film:φ350mm
Power source:3-phase,200VAC,7.5kW at peak,3.5kW at average
Air consumption:0.4MPa、100NL/min
Note:
1) The speed of packaging subject to the filling volume, size of stick, characteristic of powder and accuracy requirement.
2) The filling accuracy subject to the packaging speed, filling volume and characteristic of powder.
1.Fill anything from 2 to 12 lanes depending on the sachet’s dimension.It can be linked to the automated cartoning machine and the mending line to form a whole line.
2.The PLC software controls the whole machine. Man-machine interaction touch screens configure the function parameters.
3.This machine can automatically fill, measure, bag-make, seal,print batches, count, and finishes final products.
4.The horizontal seal uses independent servo control and has a straightforward, sturdy design.
5.The film runs steadily and has cursor adjustment and correction.
6.Vacuum feeds the storage bin continuously.
7.The filling device is removable, simple to set up, and quick to clean and sanitize.
Multi-channel stick packaging machines can be used to package daily consumer products such as instant coffee, tea, hot chocolate, salt, sugar, black or white pepper, red chili powder, chicken powder, sauces, etc.
1.Before packaged, the multi lines packing machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
Packing Detail:
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.
FAQ
Q1.Are you a manufacturer or trader?
A: Shanghai Zhuheng Industiral Co,. Ltd is a manufacturer, located in Shanghai, China. We have our own product design team.
Q2.What are the typical components of a multi-lane packing machine?
Feeding system: Delivers materials to be packaged.
Metering system: Measures the product for consistent filling.
Bagging system: Forms and seals the packaging bags.
Control system: Manages the entire packaging process.
Discharge system: Conveys finished packages out of the machine.
Q3.What factors should I consider when choosing a multi-lane packing machine?
The type of product you will be packaging
Your desired production speed
The size and weight of your packages
Q4. What kind of shipping methods can you provide?
A: By sea, by air and by international express.We will send the photo and video of machine to customer to check the machine running situation before delivery.
Q5. Do you accept customer logos and customization?
A: We accept all kinds of customization and logos for all products.
Q6. How about the product packaging? Is it easy to be damaged during transportation?
A: No. We use wooden boxes, which are very safe.
