Model:Multi lines packaging machine
Voltage:AC220V/380V 50-60Hz
Power:About 5.5kW
Production Speed:About 40-50pcs/min for one lane
Finished Bag Size:(L)50-180mm*(W)20-95mm
Max Film Width:600mm
Film Thickness:0.07-0.1mm
Filling Method:Auger Filling
Air Consumption:0.8 MPA 0.8m3/min
Machine Size:About 1600*1300*2000mm
Machine Weight:About 600kg
Note:
1) The speed of packaging subject to the filling volume, size of stick, characteristic of powder and accuracy requirement.
2) The filling accuracy subject to the packaging speed, filling volume and characteristic of powder.
Mainly stainless-steel 304 construction
Stainless-steel 304 for product touching parts
Heavy duty design suits for high speed operation
No waste of film design, no reserved film edge required
Roller type film dividing device
PLC & Touch screen HMI control
Guided servo motorized film pulling device integrated with horizontal seal
Individual servo auger dosing for each lane and automatic dosing range adjustment by PLC
Visible hopper with openable door
Intelligent PID temperature controller
Door open and machine stop interlock
No packaging film and machine stop interlock
1.Before packaged, the multi lines packing machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
Packing Detail:
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.
FAQ
Q1.Are you a manufacturer or trader?
A: Shanghai Zhuheng Industiral Co,. Ltd is a manufacturer, located in Shanghai, China. We have our own product design team.
Q2.What are the typical components of a multi-lane packing machine?
Feeding system: Delivers materials to be packaged.
Metering system: Measures the product for consistent filling.
Bagging system: Forms and seals the packaging bags.
Control system: Manages the entire packaging process.
Discharge system: Conveys finished packages out of the machine.
Q3.What factors should I consider when choosing a multi-lane packing machine?
The type of product you will be packaging
Your desired production speed
The size and weight of your packages
Q4. What kind of shipping methods can you provide?
A: By sea, by air and by international express.We will send the photo and video of machine to customer to check the machine running situation before delivery.
Q5. Do you accept customer logos and customization?
A: We accept all kinds of customization and logos for all products.
Q6. How about the product packaging? Is it easy to be damaged during transportation?
A: No. We use wooden boxes, which are very safe.
